Specifications

Type: Hydraulic Pump

Port: SAE # 6 Port

Material of Tank: Metal

Power Source: Electric

Motor Voltage: 12VDC

Mount: Horizontal Mount

Rated speed: 2850R/Min

Pump Action: Double Acting

Reservoir: Translucent Reservoir

Rated Pressure: 3200 psi (220 bar)

Function: Power Up / Power Down

Gross Weight: 33.0 lbs (15.15 kg)

Package Dimensions (L x W x H): 26 in x 11 in x 12 in (65 x 28 x 29 cm)

Features

Double-Acting Power Unit

This double-acting hydraulic power unit has a 12V DC motor (Power:1.6-3.0kw) and a 12-quart metal reservoir; it has SAE#6 ports with 3200 PSI max relief setting. The rated speed is 2850 r/min.

Easy Installation

All of our 12-volt hydraulic power units have been pre-assembled before delivery, and we provide instructions for operation so that you can install and use the hydraulic pump easily. Horizontal mount is recommended.

Wide Application

As a great power unit, this hydraulic pump can be used for many things, such as truck tailgate lift, RV leveling, scissor lift, dump trailers, lift truck, snowplow, aerial platform, road signs, material handling, wheelchair lifts, etc.

Package Includes

1 x 12 Quart Double Acting Hydraulic Pump

1 x English Manual

Several Related Accessories

(As Pics Shown)
