Descriptions

【Dual-Stage High Efficiency】: This 2-stage HI/LO gear pump features 16GPM flow rate, max 3600 RPM and 4000 PSI working pressure. It realizes faster cycle times and delivers strong hydraulic pressure for heavy-duty use

【Heavy-Duty Durable Construction】: Built with high-strength extruded aluminum housing and cast steel end plate. The sturdy structure resists impact, rust and high pressure for long service life in harsh working environments

【Standard Port & Shaft Design】: Comes with 1/2" NPT outlet port and 1" barb inlet port, equipped with 1/8" keyed shaft for clockwise rotation, perfectly matching standard log splitter hydraulic systems

【Easy & Flexible Installation】: Adopts 4-bolt hole pattern for quick mounting. It supports both horizontal and vertical shaft engines with clockwise rotation, simple to install and replace

【Wide Application Range】: Universal hydraulic pump ideal for log splitters, hydraulic presses, truck snowplows, machine tools, dump trailer lifts and other hydraulic equipment

Specifications

Inlet Port: 1" Dia. Pipe
Outlet Port: 1/2" NPT
Maximum Flow Rate: 16 GPM ±10%
Maximum Operating Pressure: 4000 PSI ±10%
Maximum Operating Speed: 3600 RPM ±10%
Housing Material: Aluminum Alloy
Applicable Engine Requirements: 5.5-7.5 HP, 3600 RPM Idle, 1440 RPM Rated Speed
Gear Pump Output Shaft Length: 1.5"
Net Weight: 16.6 lbs / 7.55 kg
